Chassis Platform Semi-Trailer for Freight Forwarders
Fine-grained steel welded construction, fifth wheel plate with replaceable 2" kingpin
Outer frame slightly angled with "Load-Lock" profile for lashing strap attachment
Note: In order to attach the straps in combination with side walls, the side walls must be opened!
Pair of additional lashing rings integrated into the outer frame, each rated at 2.5 t
24 t, two-speed landing leg, single-sided operation, with straight base, without compensation mechanism
Pull-out ladder at the rear
Side-mounted door retainers
Wheel chocks with holders
Pallet box for 32 Euro pallets (long version), ground clearance approx. 300 mm. Note: Free support leg corner dimension or rear swing clearance approx. 1,930 mm
Underrun protection, galvanized steel
Full-width rear spray flaps
Half-shell mudguards
With anti-spray mud flaps only on the last axle
Rear impact guard
"Blocker" – galvanized crosswise steel angle as forklift and hinge protection
Pair of ferry lashing eyes, marked yellow
Iajdpfx Aowyiw Ejdljt
Pallet stop on both sides, approx. 15-20 mm high, bolted design; loading height is reduced by approx. 15-20 mm
Spare wheel holder for one electronic wheel, including wheel mounting kit, basket type, brand Schoch!
Spare wheel, same brand/type as main tires, steel rim
Stainless steel toolbox, width=600/height=400/depth=500 mm, with polished, lockable door
Stake pockets
Front right: 5 rows of aluminum V-stake inserts
Front left: without stake inserts
Rear wall / rear corner posts
Rear corner posts made of steel up to the lower edge of the roof, curtain pole mount with round tube and curtain tension ratchet
Rear portal doors, 2-leaf design, each with 2 internal rotary bolt locks
Curtain
Curtain with welded horizontal and vertical straps
Quick Lock system for side curtain with central locking, on left side only
Stainless steel tension locks on right side
Customs rope all around with holder at front wall (no customs seal, not in combination with Quick Lock)
Customer labeling on side curtains and rear portal
Curtain with high-strength embedded spring steel strips, left side
(Attention! When fitted, no stake inserts front left)
Roof
Sliding roof, rear end-lift foldable upwards, sliding tarpaulin from rear to front, tarpaulin color: white
EcoLift – roof can be raised by approx. 380 mm, both sides, gas strut assisted
Optimal rain gutter at rear, upper end rail, above the doors
Paintwork
Frame: Hot-dip galvanized incl. passivation
Landing legs: black coated
Front corner posts: galvanized and painted to match front wall color
Front wall: MB 5328 blue
Rear corner posts: galvanized and painted to match rear wall
Rear wall: MB 5328 blue
Curtain: RAL 5010 gentian blue
Pallet box lid: RAL 2011 deep orange
